Intended Use
SPIROX-P is intended for Überwachung PEF (Peak Expired Flow Rate) and FEV1 (Forced Expiratory Volume in One Second) for patient use at Startseite, Kliniken and Krankenhaus. The device is konzipiert for pädiatrisch to Erwachsene patients. The simple device interface provides ease Of use for pädiatrisch patients. When the Meter is used to Monitor lung conditions such as asthma or COPD, the user should be under the Versorgung of a licensed health Versorgung professionell. A licensed health Versorgung professionell’s advice is erforderlich to understand the meaning and importance of The measured reported by the Meter and how to decide on an appropriate Behandlung plan. This Behandlung plan will tell the patient what action to take when there are changes in their peak flow measurements. Intended user of SPIROX-P is patients.
1 TECHNICAL Spezifikation
| Sensor type | Turbine |
| Measurement parameters | PEF / FEV1 |
| Memory size | 250 |
| BTPS | PEF and FEV1 results displayed at BTPS conditions |
Accuracy
| Volume Spektrum | 0.01~9.99L | Air flow Spektrum | 50 L/min ~900L/min |
| Volume accuracy | ±0.05L or ±3% | Air flow accuracy | ±10% or ±20L/min |
Anzeige Bildschirm
| Size | 1.8 inches |
| Type | LCD |
Wireless
| Wireless Technologie | Bluetooth Low Energy (4.0) |
| Output Watts | 0.0003 |
| Frequency Spektrum (MHz) | 2402.0 – 2480.0 |
| Modulation | GFSK |
Umgebung Spezifikation
| Power source | AAA1.5×2 Akkus |
|
Operation Temperature Humidity Atmosphere Altitude limit |
10 o C～40 o C 25%~85% 860hPa～1060hPa No limit |
|
Storage Temperature Humidity Atmosphere |
-20 o C～55 o C 15%~93% 500hPa～1060hPa |
Physical Spezifikation
| Height | 12.6 centimeter |
| breit | 5.4 centimeter |
| Thickness | 2.8 centimeter |
| Weight | 120g(contain Akkus and mouthpiece) |
Durable Period
| Main Unit | 3 years |
| Turbine | 2 year |
